Q91y -630W Gantry Type Steel Hydraulic Shearing Machine From Emma
Q91Y-630W gantry type hydraulic steel shearing machine mainly technical parameterNO.Parameter name and subjectNote1Shear cylindertypeYG YG520/400-780Stroke780mm630T Max shear force6300KN*Qty1piece2Pressing cylindertypeYG180/120-900Stroke900mm126TMax blank-holder force630KN*2Qty2piece3Dimension of ch......
Send Inquiry
Product Description
Q91Y-630W gantry type hydraulic steel shearing machine mainly technical parameter
| NO. | Parameter name and subject | Note | |||||||||
| 1 | Shear cylinder | type | YG YG520/400-780 | Stroke | 780mm | 630T | |||||
| Max shear force | 6300KN* | Qty | 1piece | ||||||||
| 2 | Pressing cylinder | type | YG180/120-900 | Stroke | 900mm | 126T | |||||
| Max blank-holder force | 630KN*2 | Qty | 2piece | ||||||||
| 3 | Dimension of charging box(L×W×H) | 6000×1000×900mm | |||||||||
| 4 | hydraulic pressure | 28MPa | |||||||||
| 5 | Main motor power / equipment total power | 135KW | |||||||||
| 6 | Power | 380V/3Ph,50HZ | |||||||||
| 7 | Width of gantry shear material | 1000mm | |||||||||
| 8 | Length of pressing material/Feed opening | 1000mm/900mm | |||||||||
| 9 | Cutter length/Shear opening | 1000mm/500mm | |||||||||
| 10 | Cutting speed | 2~3times/mins | |||||||||
| 11 | Cutting angle | 9degree | |||||||||
| 12 | Max shearing range 8b≤440N/mm2 | Round steel:Φ140mm | |||||||||
| Square steel:135×135mm | |||||||||||
| Steel sheet:60×700mm | |||||||||||
| 13 | Motor | type | Yx3-280S-6 | Rated power | 45kw | ||||||
| nominal speed | 980rmp | Qty | 3pcs | ||||||||
| 14 | high pressure plunger pump | type | A4V250 | nominal pressure | 31.5Mpa | ||||||
| specified discharge | 250ml/r | Qty | 3stand | ||||||||
| 15 | water cooler | type | GLC5-25 | nominal pressure | 1.0Mpa | | |||||
| heat dissipation area | 25m2 | Qty | 1stand | ||||||||
| 16 | Cooling tower | type | CT-40 | cooling capacity | 40ton / hour | ||||||
| Power | 1.1kw | Qty | 1piece | ||||||||
