Taiwan Made Cheap Precision CNC Milling Machine Tool

Product Description

Taiwan made cheap precision cnc milling machine tool

Creator Precision Co., Ltd. Was established in Taiwan at 1986. In 1997, Creator Industry (Suzhou) Co., Ltd. Was found to extend Mainland China market. Till now, the registered capital is USD 5, 080, 000. The new factory covers 24, 680sqms and holds a building area of 19, 000sqms. There are 250 employers which assure the annual production at least as 600 sets of EDM and 100 sets of VMC.

Features:
1.Door type structure break tradition and provide with safety and beautiful appearance.
2.Equipped with built-in spindle.Put in use on mirror mold and exquisite mold
3.Processing on tiny parts. Mold electrode and electronic parts assures high steady and high precision
4.Meehanite metal casting with symmetrical design assures no deformation
5.Utilizes a 3axes feed system and a C3precision grade ball screw with a high precision linear slide and pre-tension processing to ensure machine position accuracy and to prevent thermal strain.

ITEM	UNIT	CEM650S
X/Y/Z axes travel	mm	600/500/250
Distance fro. Spindle nose to work table	mm	100-350
Worktable dimensions	mm	600*500
Maximum load	kg	200
T-slot	mm	518100
Type	type	BT-30
Rotation speed	rpm	24000
Transmission	type	Built-in
Spindle motor	kw	7.5
Spindle cooling	type	Spindle cooling machine
X/y/z rapid feed	m/min	101010
Cutting feed rate	mm/min	1-7000
3-axes motor	kw	1.3
Tool storage	type	Vertical type
Tool storage volume	pcs	8
Maximum tool diameter	mm	40
Maximum tool length	mm	80
Maximum blade weight	kg	3
Tool selection	type	Fixed type
Power requirement specification	kva	10
Machine dimensions	mm	198022002570
Machine weight	kg	2800
