82mm Spindle Bore Engine Metal Lathe Machine
CE High precision industrial metal lathe machine1.Features:Precision ground and supersonic frequency hardened bed ways.The spindle is supported with precision roller bearing.Headstock gears are made of high quality steel,ground and hardened.2.Big spindle bore 82mm.3.Most popular in the world.4.C624......
Send Inquiry
Product Description
CE High precision industrial metal lathe machine
1.Features:
Precision ground and supersonic frequency hardened bed ways.
The spindle is supported with precision roller bearing.
Headstock gears are made of high quality steel,ground and hardened.
2.Big spindle bore 82mm.
3.Most popular in the world.
4.C6246D/1500 Specification as following:
5.FAQ
1.Question : Are you a factory or trading company ?
Answer: We are an SGS recognized OEM / ODM manufacturer factory with export license. we have an experienced team made up of "A" player who have a passion for doing something great to create more value for customers world-wide.
2. Question : Why choose cooperate with us ?
Answer :
--Reliable Quality and All components from world leading suppliers ;
--Cost-effective export infrastructure and total supply chain management ;
3. Question : Can you do OEM ?
Answer : Yes, we have the ability to do OEM / ODM to meet clients' requirements.
4. Question : How about machine Warranty ?
The warranty period is general 13 months after B/L date. During the warranty period, we will provide free replacement parts (EXW) which are easy damaged. And also parts caused by machine itself quality problems. Meanwhile, the machine should be under normal operation according to Operation Manual.(Except for improper operation or man-made damaged by buyers)
Welcome you contact :Ms Alice
Mobile:0086-15357788287 /0086-17398394840
1.Features:
Precision ground and supersonic frequency hardened bed ways.
The spindle is supported with precision roller bearing.
Headstock gears are made of high quality steel,ground and hardened.
2.Big spindle bore 82mm.
3.Most popular in the world.
4.C6246D/1500 Specification as following:
| HIGH PRECISION &HEAVY DUTY INDUSTRIAL LATHE | ||||
| Model | C6246D×1000 | C6246D×1500 | ||
| Max.swing over bed | Φ460mm | |||
| Height of center | Φ230mm | |||
| Distance between centers | 1000mm 1500mm | |||
| Width of bed | 300mm | |||
| Cutting tool max.section | 25X25mm | |||
| Total travel of top slide | 120mm | |||
| Spindle bore | 82mm | |||
| Spindle nose | D1-8 | |||
| Spindle morse taper in nose in sleeve | ME90/MT NO.5 | |||
| Spindle speed number | 12 | |||
| Spindle speed range | 25-2000rpm | |||
| Leadscrew diameter and thread | 35MMX4TPI | |||
| Thread imperial pitches | 4-112(50Nos ) | |||
| Thread metric pitches | 0.25-7(24Nos) | |||
| Diameter pitches DP/DP | 4-112(50Nos) | |||
| Diameter pitches MP/MP | 0.25-14(34Nos) | |||
| Longitudinal feeds (imperial/metric) | 0.0011"-0.0316"(0.01mm-0.286mm)50Nos | |||
| Cross feeds)imperial/metric) | 0.00024"-0.0068"(0.01m-0.286mm050Nos | |||
| Travel of tailstock quill | 120mm | |||
| Tails stock quill | 60mm | |||
| Taper tailstock quill | MT 4 | |||
| Spindle drive motor | 5.5KW | |||
| Coolant pump motor | 0.04KW | |||
| Machine space required | 88"X36"X49" | |||
| Packing space required | 93"X39"X62" | |||
| Net weight | 1730/2060kgs | |||
| Gross weight | 1980/2310kgs | |||
5.FAQ
1.Question : Are you a factory or trading company ?
Answer: We are an SGS recognized OEM / ODM manufacturer factory with export license. we have an experienced team made up of "A" player who have a passion for doing something great to create more value for customers world-wide.
2. Question : Why choose cooperate with us ?
Answer :
--Reliable Quality and All components from world leading suppliers ;
--Cost-effective export infrastructure and total supply chain management ;
3. Question : Can you do OEM ?
Answer : Yes, we have the ability to do OEM / ODM to meet clients' requirements.
4. Question : How about machine Warranty ?
The warranty period is general 13 months after B/L date. During the warranty period, we will provide free replacement parts (EXW) which are easy damaged. And also parts caused by machine itself quality problems. Meanwhile, the machine should be under normal operation according to Operation Manual.(Except for improper operation or man-made damaged by buyers)
Welcome you contact :Ms Alice
Mobile:0086-15357788287 /0086-17398394840
