Brake Drum Lathe Machine (T8465)
Product Description:This equipment is a kind of lathe.It can fulfill the reparation of the brake drum, disc and shoe of auto-mobiles from mini-car to heavy trucks. The unusual feature of this equipment is its twin-spindle each other perpendicular structure. The brake drum/shoe can be cut on the firs......
Send Inquiry
Product Description
Product Description:
This equipment is a kind of lathe.
It can fulfill the reparation of the brake drum, disc and shoe of auto-mobiles from mini-car to heavy trucks.
The unusual feature of this equipment is its twin-spindle each other perpendicular structure.
The brake drum/shoe can be cut on the first spindle and the brake disc can be cut on the second spindle.
It has higher rigidity, accurate workpiece positioning and is easy to operate.
It is fit up with out-board supporter to advance loading. Capability of first spindle. Besides, this equipment is fit up with set of crane which turn loading and unloading a heavy break drum into easier.
This equipment meets the requirement of the state standard (GB12064), brake drum cutting machine.
Parameters | |
| Model | T8465 |
| Drum dia. Capacity | Φ 180- Φ 650 mm |
| Disc dia. capacity | ≤ Φ 500 mm |
| Spindle speed (3 steps) | 25, 40, 70 r/min |
| Toolpost travel | 250 mm |
| Feed rate | 0.16 mm /min |
| Motor | 1.1 Kw / 1400 rpm |
| Overall dimension (L x W x H) | 800x975x 940 mm |
| Packing dimensions (L x W x H) | 1330x960x 1230 mm |
| N.W./G.W. | 580/ 650 kg |
