Product Description
Features :
Super voice frequency heated bed ways.
Hardened and grounded gears in the headstock.
With 2 precision D degree taper roller bearings on the spindle.
Integrated deluxe cast iron floor stand.
Tolerance test certificate, test flow chart included.
Product main technical specifications:
| SPECIFICATION | CM6241 |
| Swing over bed | 410mm(16") |
| Swing over cross slide | 255mm(10") |
| Swing in gap | 580(23") |
| Length of gap | 250(10") |
| Distance between centers | 1000mm(40") /1500mm(60'') |
| Center height | 205(10'') |
| Width of bed | 250(10") |
| Spindle nose | D1-6 |
| Spindle bore | 52mm(2") |
| Taper of spindle bore | No.6Morse |
| Range of spindle speed | 16 changes 45-1800r/min |
| Max.travel of compound rest | 140mm(5-1/2") |
| Max.travel of cross slide | 210mm(8-1/4") |
| Leadscrew pitch | 4T.P.I. |
| Max.Section of tool | 20×20mm(13/16") |
| Longitudinal feeds range | 0.05-1.7mm/rev(0.002"-0.067"/rev) |
| Cross oeeds range | 0.025-0.85mm(0.001"-0.0335"/rev) |
| Metric threads range | 39kinds 0.2-14mm |
| Inch threads range | 45kinds 2-72T.P.I |
| Diametrical pitchesrange | 21kinds 44D.P. |
| Module pitches range | 18kinds 0.3-3.5M.P. |
| Dia.of tailstock sleeve | 50mm(2") |
| Travel of tailstock sleeve | 120mm(4-3/4") |
| Morse taper of tailstock sleeve | No.4 Morse |
| Cross adjustock | ±13mm(±1/2") |
| Power of main motor | 2.8/3.3kw(3.8/4.5HP)3PH |
| Power of coolant pump | 0.1KW(1/8HP),3PH |
| Overall dimension(L×W×H) | 1940/244×850×1300mm |
| Packing size(L×W×H) | 2060/2560×900×1640mm |
| Net weight/Gross weight | 1160/1350 1340/1565kg |
1:How can I choose the most suitable machines ?
A: Please tell me your specifications ,we can choose the best model for you , or you can choose the exact model .
You can also send us the products drawing ,we will choose the most suitable machines for you .
2: What's your main products of your company?
A: We specialized in all kinds of machines ,such as CNC Lathe Machine ,CNC Milling Machine ,Vertical Machining Center ,
Lathe Machines ,Drilling Machine ,Radial Drilling Machine ,Sawing Machine ,Shaper machine and so on .
3: Where is our factory located? How can I visit there?
A : Our factory is located in Tengzhou City ,Shandong Province,277500 China. You are warmly welcomed to visit us.
4. What is your trade terms?
A : FOB, CFR and CIF all acceptable.
5: What's the Payment Terms ?
A : T/T ,30% initial payment when order ,70% balance payment before shipment ;
Irrevocable LC at sight .
5: What's the MOQ?
A: 1 set .(Only some low cost machines will be more than 1 set )
