High Precision Torno Conventional Turning Machine Horizontal Lathe Gh1640zx
MODELSGH1640ZXCAPACITY Max.swing over bed400mmMax.swing over cross slide 250mmMax. swing over gap 660mmDistance between centers 1000mmMax turning length850mmBed with 336mmHEADSTOCK Spindle bore80mmSpindle mount D1-8Taper bore of spindleMT-7Steps of spindle speed 12Range of spindle speed42-1800rpm GE......
Send Inquiry
Product Description
| MODELS | GH1640ZX |
| CAPACITY | |
| Max.swing over bed | 400mm |
| Max.swing over cross slide | 250mm |
| Max. swing over gap | 660mm |
| Distance between centers | 1000mm |
| Max turning length | 850mm |
| Bed with | 336mm |
| HEADSTOCK | |
| Spindle bore | 80mm |
| Spindle mount | D1-8 |
| Taper bore of spindle | MT-7 |
| Steps of spindle speed | 12 |
| Range of spindle speed | 42-1800rpm |
| GEARBOX | |
| Range of longitudinal feeds | 0.04-2.46mm |
| Range of cross feeds | 0.02-1.23mm |
| Number of inch threads | 61 |
| Range of inch threads | 1-5/8 - 72 T.P.I. |
| Number of metric threads | 24 |
| Range of metric threads | 0.5-20mm |
| Number of D.P threads | 45 |
| Range of D.P threads | 96-3 1/4D.P |
| Number of module threads | 20 |
| Range of module threads | 0.25-10M.Pmm |
| CARRIAGE | |
| Max.Tool size | 25x25mm |
| Max.compound slide travel | 130mm |
| Max.cross slide travel | 280mm |
| TAILSTOCK | |
| Tailstock sleeve travel | 130mm |
| Taper in tailstock sleeve | MT-4 |
| MISCELLANEOUS | |
| Main motor | 5.5kw (7.5HP) |
