Maximum Drilling Diameter 63mm Radial Drilling Machine,
Features1. Key components of model RD63 radial drilling machine are made of high-strength cast iron or special steel;2. Advanced heat treatment results in durable parts and components;3. High precision components are available due to specialized pro......
Send Inquiry
Product Description
Features
1. Key components of model RD63 radial drilling machine are made of high-strength cast iron or special steel;
2. Advanced heat treatment results in durable parts and components;
3. High precision components are available due to specialized processing;
4. The hydraulic power can realize spindle variable speed flexibly on the safe side;
5.16-steps spindle rotation speed and feed is available in heavy cutting;
6. Quick, safe clamping and unclamping operations are achievable;
7. The mechanical, electrical and hydraulic control over the headstock makes the machine operation easier and quicker.
Standard Accessories
1. Box shape worktable
2. Taper sleeve
3. Tool releasing Wrench
4. Drift
5. Eyelet bolts.
Optional Accessories
1. Quick instead Chuck
2. Tapping chuck.
1. Key components of model RD63 radial drilling machine are made of high-strength cast iron or special steel;
2. Advanced heat treatment results in durable parts and components;
3. High precision components are available due to specialized processing;
4. The hydraulic power can realize spindle variable speed flexibly on the safe side;
5.16-steps spindle rotation speed and feed is available in heavy cutting;
6. Quick, safe clamping and unclamping operations are achievable;
7. The mechanical, electrical and hydraulic control over the headstock makes the machine operation easier and quicker.
Standard Accessories
1. Box shape worktable
2. Taper sleeve
3. Tool releasing Wrench
4. Drift
5. Eyelet bolts.
Optional Accessories
1. Quick instead Chuck
2. Tapping chuck.
| Specification | RD63X2500 |
| Max.Drilling capacity (mm) in steel / In Cast Iron | 63 / 80 |
| Distance spindle axis to column generating line (mm) | 450-2500 |
| Diameter of column (mm) | 450 |
| Spindle taper | MT5 |
| Spindle travel (mm) | 400 |
| Spindle speeds range (r/min) | 20-1600 |
| Spindle speeds series | 16 |
| Range of Spindle feeds (r/min) | 0.04-3.2 |
| Spindle feeds | 16 |
| Max.Distance spindle nose to working surface of base (mm) | 400-1600 |
| Dimension of worktable (mm) | 950×630×500 |
| Dimension of base (mm) | 2900×1250×250 |
| Machine overall Size (mm) | 3110×1250×3150 |
| Power of Main motor (KW) | 5.5 |
| Clamping type | hydraulic |
| G.W/N.W (kg) | 8000/7000 |
| Packing dimension (mm) | 3470×1470×2350 |
