14 " Heavy Duty Drill Press 550W Bench Type (ZQJ4119K)
01) Motor (W): 550/65002) Swing (mm): 35603) Chuck size (mm): 3 to 1604) Max drilling capacity (mm): 2005) Taper: MT206) Spindle travel (mm): 8007) No. of speed: 12/1608) Speed range (rpm)/50Hz: 120-2,580/120-3,00009) Speed range (rpm)/60Hz: 140-3,050/140-3,60010) Overall height ......
Send Inquiry
Product Description
| 01) Motor (W): 550/650 |
| 02) Swing (mm): 356 |
| 03) Chuck size (mm): 3 to 16 |
| 04) Max drilling capacity (mm): 20 |
| 05) Taper: MT2 |
| 06) Spindle travel (mm): 80 |
| 07) No. of speed: 12/16 |
| 08) Speed range (rpm)/50Hz: 120-2,580/120-3,000 |
| 09) Speed range (rpm)/60Hz: 140-3,050/140-3,600 |
| 10) Overall height (mm): 1,000 |
| 11) Column diameter: 80mm, Chuck guard collar diameter: 60mm,Quill diameter: 52mm |
| 12) Working table: 290*290mm (310mm round table optional) |
| 13) Packing size (mm): 950x590x370 |
| 14) N/G Weight (kg): 82/86 |
| 15) Units/20-foot container: 132 |
01) Motor (W): 550/650
02) Swing (mm): 356
03) Chuck size (mm): 3 to 16
04) Max drilling capacity (mm): 20
05) Taper: MT2
06) Spindle travel (mm): 80
07) No. of speed: 12/16
08) Speed range (rpm)/50Hz: 120-2,580/120-3,000
09) Speed range (rpm)/60Hz: 140-3,050/140-3,600
10) Overall height (mm): 1,000
11) Column diameter: 80mm, Chuck guard collar diameter: 60mm,Quill diameter: 52mm
12) Working table: 290*290mm (310mm round table optional)
13) Packing size (mm): 950x590x370
14) N/G Weight (kg): 82/86
15) Units/20-foot container: 132
