14 " Variable Speed Drill Press (ZQJ4119W)
01) Drilling capacity (chuck size): 16mm02) Spindle nose taper: MT203) Swing: 356mm04) Distance chuck to upright face: 178mm05) Spindle travel: 80mm06) Number of speeds: variable07) Speed range: 150 to 2,300rpm08) Maximum distance spindle to table: 480mm09) Maximum distance spindle to base:......
Send Inquiry
Product Description
| 01) | Drilling capacity (chuck size): 16mm |
| 02) | Spindle nose taper: MT2 |
| 03) | Swing: 356mm |
| 04) | Distance chuck to upright face: 178mm |
| 05) | Spindle travel: 80mm |
| 06) | Number of speeds: variable |
| 07) | Speed range: 150 to 2,300rpm |
| 08) | Maximum distance spindle to table: 480mm |
| 09) | Maximum distance spindle to base: 670mm |
| 10) | Working table surface size:290*290mm (310mm round table optional) |
| 11) | Working base surface size:205*205mm |
| 12) | Overall base size: 440 x 260mm |
| 13) | Column diameter: 80mm,Collar diameter: 58mm,,Quill diameter: 52mm |
| 14) | Overall height: 1,070mm |
| 15) | Motor power: 550W, 230V |
| 16) | Weight: 77kg |
| 17) | Load quantity for 20 feet container: 220 pieces |
| 18) | Minimum order quantity: 40 |
01) Drilling capacity (chuck size): 16mm
02) Spindle nose taper: MT2
03) Swing: 356mm
04) Distance chuck to upright face: 178mm
05) Spindle travel: 80mm
06) Number of speeds: variable
07) Speed range: 150 to 2,300rpm
08) Maximum distance spindle to table: 480mm
09) Maximum distance spindle to base: 670mm
10) Working table surface size:290*290mm (310mm round table optional)
11) Working base surface size:205*205mm
12) Overall base size: 440 x 260mm
13) Column diameter: 80mm,Collar diameter: 58mm,,Quill diameter: 52mm
14) Overall height: 1,070mm
15) Motor power: 550W, 230V
16) Weight: 77kg
17) Load quantity for 20 feet container: 220 pieces
18) Minimum order quantity: 40
